Cost-Effective Flake Ice System for Efficient Cooling Solutions

Customization:	Available
Ice Making:	Flowing
Cooling Way:	Air-cooled

Send Inquiry

Product Description

Technical Specifications

Model NO.

LR-10T

Automation

Full Automation

Unit Structure

Integral

Ice Temperature

-5℃ ~ -10℃

Ice Shape

Flake Ice

Application

Concrete Mixing / Textile

Input Power

23.5kw

Dimension

2370*1950*1715mm

Product Description

❄️

Innovative Ice Dyeing Solutions

Ice dyeing is a method where melting ice carries dissolving dyes to create natural flow and random color mixing. This unpredictable and dazzling effect creates unique creative results that cannot be copied.

The flake ice machine control system adopts automatic microcomputer control via PLC. It manages the evaporator operation and water supply system coordination to achieve maximum efficiency. Safety features include water shortage protection, full ice protection, and compressor overload protection.

Core Features

Premium Components: Utilizes Germany Bitzer, Italy Refcomp, or Taiwan Hanbell compressors.
Advanced Control: Automatic LG PLC controller with Human-Computer Interaction (HCI) support.
Hygiene Standard: SS314 evaporator ensures hygiene-grade flake ice production.
High Efficiency: Optimized evaporator design produces more ice than standard ambient conditions.
Safety Intelligence: Complete self-protection for high/low voltage and phase sequence.

Model Parameter Table

Model	Ice Capacity (kg/24h)	Power Supply	Total Power (kw)	Refrigerant	Dimension (mm)	Weight (kg)
LR-05T	500	3P/380V/50HZ	2.5	R404A	1310890780	195
LR-1T	1,000	3P/380V/50HZ	4.8	R404A	1310970880	227
LR-2T	2,000	3P/380V/50HZ	8.5	R404A	150010951040	423
LR-5T	5,000	3P/380V/50HZ	19.6	R404A	170016501450	760
LR-10T	10,000	3P/380V/50HZ	32.5	R404A	250020001700	1260
LR-20T	20,000	3P/380V/50HZ	63	R22/R404A	310021602050	2860
LR-30T	30,000	3P/380V/50HZ	86	R22/R404A	350027002350	3240

Support & Service

Pre-sale Service
24/7 technical consultation and customized cooling project schemes.

Sales Support
Strict quality control and delivery tracking from order to destination.

After-sales
Responsible for quality issues and providing technical backup anytime.

Technical Guidance
Installation support, debugging assistance, and operator training.

Frequently Asked Questions (FAQ)

1. What are the primary applications for flake ice systems?

Flake ice is widely used in concrete mixing for construction, textile printing and dyeing, seafood processing, and industrial chemistry cooling due to its rapid cooling efficiency.

2. How does the intelligent control system work?

The system utilizes an automatic PLC (Programmable Logic Controller) that monitors water levels, ice fullness, and electrical parameters, automatically stopping the machine if a fault is detected to protect the components.

3. What brands of compressors are used in these machines?

To ensure superb stability and reliability, we integrate high-end compressors from Germany Bitzer, Italy Refcomp, or Taiwan Hanbell, depending on the specific model and customer requirements.

4. Can the ice machine handle non-standard requirements?

Yes, our R&D team provides customized services (OEM & ODM) to find the best solutions if standard models do not satisfy your specific capacity or installation needs.

5. Is installation support available for international customers?

Absolutely. we provide comprehensive installation guidance, debugging support, and training services to ensure your staff can operate and maintain the equipment effectively.
