Manufacturer Automatic Rotary Printing Heat Press Machine New Used Condition Garment Umbrella Heat Transfers Multicolor Color

Still deciding? Get samples of $ !
Request Sample

Product Description

Basic Specifications

Model NO.
ZS
Plate Type
Relief Printing
Color & Page
Multi-Colour
Automatic Grade
Automatic
Printing Speed
Max Speed 48m/H
Drum
Single Layer Dia 420mm
Conveyor Belt
Yes
Paper
Sublimation
Transport Package
Wooden Carton
Specification
420*1700/1900
Trademark
ZS
Production Capacity
2000 Pieces/Yr

Product Description

Product name Fabric Pieces of Textile Sport Jersey Sublimation Heat Press Machinery
Working width 1200/1700/1900mm
After service 12 months Guanrantee, Liftime Technical Guidiance
Conveyor belt Yes
Paper Sublimation
⚙️
High Pressure Dye Heat Transfer Digital Textile Printing Machine is designed for users seeking a reliable and efficient printing solution, particularly those in manufacturing plants, home use, printing shops, and advertising companies.
Diameter (Width) 1200mm (Width) 1700mm (Width) 1900mm Speed m/H Power (kw)
200 mm 550 kg 750 kg - 35--48m 7.5
320 mm 800 kg 1000 kg 1300 kg 80--120m 14.5
420 mm 1200 kg 1300 kg 1400 kg 120--180m 28
610 mm 1600 kg 1900 kg 2100 kg 180--240m 44
800 mm - 2500 kg 2700 kg 280--350m 70
🛡️
This machine features a high safety level, ensuring a secure printing process and minimizing the risk of accidents, which is a top priority for many users.
🌍
The product is available in various showroom locations worldwide, including the United States, South Korea, South Africa, and Australia, providing users with convenient access to demonstrations and trials.
🌡️
With a printing temperature range of 0-400, this digital textile printing machine is capable of handling a wide variety of applications, including garment printing, making it a versatile option for diverse printing needs.

Product Visuals

Frequently Asked Questions

What materials can be used with this heat press machine?
This machine is specifically designed for sublimation paper and fabric pieces, making it ideal for textile sport jerseys and various garment applications.
What is the printing speed of the ZS model?
The printing speed varies by drum diameter, ranging from 35m/H up to 350m/H for the largest 800mm diameter models.
What kind of after-sales support is provided?
We offer a 12-month guarantee along with lifetime technical guidance to ensure your machine operates smoothly.
What is the maximum operating temperature?
The machine features a wide printing temperature range of 0-400, allowing for precision across different textile types.
Is the machine suitable for high-volume production?
Yes, with an automatic grade system and production capacity of up to 2000 pieces per year, it is well-suited for manufacturing plants and printing shops.
Does the machine include a conveyor system?
Yes, the machine is equipped with a conveyor belt to facilitate continuous and efficient material handling.
